**Isomorphic** · 15 Feb 2012, 16:36

Please try adding to your server.properties the following line:

Code:

jndi.messaging.java.naming.provider.url=t3://localhost:7001

And use this code to test your configuration in weblogic:

Code:

public static Context getInitialContext() throws javax.naming.NamingException {
        Properties p = new Properties();
        p.put(Context.INITIAL_CONTEXT_FACTORY, "weblogic.jndi.WLInitialContextFactory");
        p.put(Context.PROVIDER_URL, "t3://localhost:7001");
        return new javax.naming.InitialContext(p);
    }

    public static void main(String[] args) {
        // TODO Auto-generated method stub
        Context context = null;
        TopicSession session = null;
        TopicPublisher publisher  = null;
        TopicConnection connection = null;
        TextMessage message = null;
        try {
               context = getInitialContext();
               TopicConnectionFactory factory = (TopicConnectionFactory)context.lookup("TopicConnectionFactory");
               Topic topic = (Topic)context.lookup("feedbackChannel");
               // create the connection and session
               connection = factory.createTopicConnection();
               session = connection.createTopicSession(false, Session.AUTO_ACKNOWLEDGE);
               // create a publisher
               publisher = session.createPublisher(topic);
               publisher.setDeliveryMode(DeliveryMode.NON_PERSISTENT);
               // create the message
               message = session.createTextMessage();
               message.setText("Hello...");
               publisher.publish(message);
               //
        } catch (Exception e) {
            e.printStackTrace();
        }
        try {
        session.close();
        publisher.close();
        context.close();
        connection.close();
        } catch(Exception e) {}
    }

**lextra** · 17 Feb 2012, 08:02

Thank you very much for your assistance.

Your test code works if I use 'jms/SmartClientTopicConnectionFactory' and 'jms/feedbackChannel' as parameters. Well, at least the code doesn't generate any errors and the WebLogic Console Monitoring screen shows the 'Messages Received' incrementing accordingly. The counter is also incremented when I use the ISCMessageDispatcher so it seems that the MessageDispatcher is working at least partially.

Are there any additional debugging parameters that I can set that will provide more information? Thanks again for you assistance.

Code:

=== 2012-02-17 16:47:45,966 [ng)'] DEBUG JNDI - passing the following environment to JNDI: {
    "java.naming.factory.initial":"weblogic.jndi.WLInitialContextFactory",
    "java.naming.provider.url":"t3://localhost:7010"
}
=== 2012-02-17 16:47:46,216 [ng)'] DEBUG ProxyHttpServletResponse - Using charset: UTF-8 (CompressionFilter)
=== 2012-02-17 16:47:46,232 [ng)'] ERROR JMSMessageDispatcher - Unable to deliver jms message
java.lang.NullPointerException
	at com.isomorphic.messaging.JMSMessageDispatcher.iscMessage(JMSMessageDispatcher.java:227)
	at com.isomorphic.messaging.JMSMessageDispatcher.onMessage(JMSMessageDispatcher.java:179)
	at weblogic.jms.client.JMSSession.onMessage(JMSSession.java:4659)
	at weblogic.jms.client.JMSSession.execute(JMSSession.java:4345)
	at weblogic.jms.client.JMSSession.executeMessage(JMSSession.java:3821)
	at weblogic.jms.client.JMSSession.access$000(JMSSession.java:115)
	at weblogic.jms.client.JMSSession$UseForRunnable.run(JMSSession.java:5170)
	at weblogic.work.SelfTuningWorkManagerImpl$WorkAdapterImpl.run(SelfTuningWorkManagerImpl.java:528)
	at weblogic.work.ExecuteThread.execute(ExecuteThread.java:209)
	at weblogic.work.ExecuteThread.run(ExecuteThread.java:178)

**Isomorphic** · 17 Feb 2012, 15:59

It looks like your config is right now, but your code is trying to deliver a null message:

Code:

messageDispatcher.deliver(new ISCMessage(CHANNEL_NAME, null));

We should probably report this better, but this is invalid. Empty String ("") would be fine.

**lextra** · 21 Feb 2012, 08:49

As you said, the configuration on the server seems to be correct. Thank you!
A message is created successfully and SmartClient receives it from JMS.

The problem now is that when JMSDispatcher forwards the message to the Client, the channel name includes the WebLogic module name as seen in the log entry below.
The dispatcher appears to send a message to the result of Topic.getTopicName() which in my case is different from the declared channel name.

Just to recap, my configured channel name is feedbackChannel. WebLogic 11g(10.3.5)

Code:

=== 2012-02-21 16:58:51,166 [ng)'] DEBUG JMSMessageDispatcher - Received message from JMS
=== 2012-02-21 16:58:51,166 [ng)'] DEBUG JMSMessageDispatcher - Decoded jmsMessage for channel: SmartClientModule!feedbackChannel data: FromStandardJMS
=== 2012-02-21 16:58:51,166 [ng)'] DEBUG ISCMessageDispatcher - sending message to channel: SmartClientModule!feedbackChannel

**Isomorphic** · 22 Feb 2012, 17:00

Looking at this, it seems like a bug in WebLogic - it's WebLogic that's returning the special "SmartClientModule!feedbackChannel" String from getTopicName(), it does not happen in JBoss, and in WebLogic there does not appear to be an API by which we can find out the original channel name from either the Message or Topic. So we'd recommend just implementing a workaround for now.

**Isomorphic** · 22 Feb 2012, 17:02

FYI someone has recently posted about this to Oracle's forums, showing very simple code that strongly suggests this is a bug. No response yet.

**lextra** · 22 Feb 2012, 21:47

Thank you. I posted that question in the Oracle forum. :-) I am also pursuing this directly through our Oracle support.

Any advice for coding a workaround? A suggested override point?
It seems to me that I would need to modify the result from getTopicName() ... I can feel the rumblings of a "pay for a patch" response. :-))
Appreciate all your help.

**Isomorphic** · 23 Feb 2012, 03:25

Theres nothing to patch on our end..

Probably the best workaround is to deliver the module name to the browser somehow and then subscribe under both the original name and the name with the WebLogic-specific module prefix.

**lextra** · 23 Feb 2012, 03:42

I can see that WebLogic has "worked this way" since at least version 9.
Has the Realtime Messaging Module been tested with WebLogic?

**Isomorphic** · 23 Feb 2012, 03:56

Yes it has. Not sure where you're getting your information, but this prefixing bug, if it's been there a while, is probably environment or deployment-model specific.

**lextra** · 23 Feb 2012, 06:01

Fair enough.
I just made a fresh install of WebLogic 9 and performed the same steps that I used with v. 11g(10.3.5):
Created JMS Server: SmartClientJMSServer
Created JMS Module: SmartClientModule
->Created Subdeployment: SmartClientSub
->Created TopicFactory: SmartClientConnectionFactory
->Created Topic: feedbackChannel

I then deployed my test application (a simple war structure) web.xml and weblogic.xml.
Nothing any more fancy than that.
All I do know is that I get the same result from getTopicName in both versions of WebLogic. ModuleName!Topic.

I am waiting for Oracle support to get back to me and will post any news.
I would gladly share my test project if other WebLogic users would find it useful.

As always thanks for your help.

-- btw, I tried the your proposed work around of subscribing twice and was unsuccesful.

**lextra** · 24 Feb 2012, 00:42

The eureka moment.

The messaging module assumes that the jndi-name (SmartClient channel name) and the Topic name are the same. I changed the jndi-name to match the WebLogic
"prefixed" Topic name et voila, the messages arrive at the client. This doesn't seem very portable though.

Cheers

**lextra** · 24 Feb 2012, 07:57

Just to complete the thread, this is not a WebLogic bug.

http://docs.oracle.com/cd/E12840_01/wls/docs103/jms/implement.html
Under "Use a Reference"
"
The value of queueName and/or topicName string is defined by:
-
A string is defined by JMS_Server_Name/Module_Name!Destination_Name (for example, myjmsserver/myModule-jms!mydestination). When referencing a destination in an interop module, the string is defined by JMS_Server_Name/interop-jms!Destination_Name (for example, myjmsserver/interop-jms!mydestination).

Note: To reference destination in releases prior to WebLogic 9.0, use a string defined by JMS_Server_Name!Destination_Name (for example, myjmsserver!mydestination).
"

**Isomorphic** · 24 Feb 2012, 08:01

??

WebLogic's documentation says they do this, that doesn't make it not a bug if it's not to spec. WebLogic still appears to be the odd man out here.

Of course, Oracle is now in a position to change an ambiguous spec to match their implementation, so the point may be moot :/
